− 36 −

ENGLISH GERMAN FRENCH ITALIAN SPANISH



 Replace the safety cable, fixing to the base as shown.



 Install the cover over the speaker base.



 Install the screws from the bottom of the speaker base.



 Spread a soft cloth over the floor in order to prevent

damaging the surface of the speaker.



 Place the speaker on its side.

󰝟

Speaker

󰝟

Speaker

Speaker base

Screw

Speaker base cover



 Stand the speaker upright.

Screws X4

Safety cable
